Xinyang, as a professional Sheet Metal Fabrication for Casings manufacturer and supplier in China, boasts years of experience in precision sheet metal processing. Sheet metal processing encompasses laser cutting, bending, stamping, welding, and painting, using materials including steel, aluminum, and stainless steel. Our aim is to manufacture equipment enclosures with high structural strength, excellent protective performance, precise dimensions, and aesthetically pleasing designs. We utilize advanced equipment and mature processes, focusing on producing two core protective sheet metal solutions: general-purpose protective enclosures for workshops and high-sealing protective enclosures for industrial applications.
|
Features |
Description |
Advantages/Results |
|
Base material and thickness |
1.2mm SPCC cold-rolled steel sheet |
Economical and durable, providing good rigidity and basic protection |
|
Key processes |
Laser cutting (precision ±0.1mm) + CNC bending (precision ±0.1mm) |
Precise dimensions, clear outlines, and tight seams |
|
Surface treatment |
Electrostatic powder coating (epoxy/polyester powder coating, 80-100μm) |
Scratch-resistant, corrosion-resistant, aesthetically pleasing, and easy to clean |
|
Safety design |
Rounding all sharp edges |
Eliminates the risk of personnel scratches |
|
Cable management |
Multiple pre-drilled holes + adjustable cover/sealing ring |
Highly compatible, sealed and dustproof |
|
Maintenance methods |
Magnetic/quick-lock access door |
Tool-free opening, convenient and efficient maintenance |
|
Compatibility & cost |
Compatible with 5-20kg small and medium-sized arms; standard hole positions are micro-adjustable |
No mold required, saving costs; rapid deployment |
|
Typical application scenarios |
Suitable for dry and dusty environments such as electronic assembly, general machining, laboratories, warehousing and logistics, and scientific research and education. |
Economical and efficient basic protection solution |
|
Features |
Description |
Advantages/Results |
|
Base material and thickness |
1.5mm High-Strength Aluminum Alloy (5052/6061) or 304/316 Stainless Steel |
Extreme strength, lightweight, and excellent corrosion resistance, adaptable to harsh environments |
|
Key processes |
Precision Stamping + CNC Finishing |
High-precision molding of complex structures ensures assembly consistency |
|
Core protection level |
IP65/IP66 Fully Sealed (Seams Embedded with Professional Oil-Resistant Silicone Sealing Strips) |
Complete dustproof protection, withstands high-pressure water washing (60-100 Bar), and isolates oil, moisture, and chemicals |
|
Heat dissipation design |
Built-in Louvered Ventilation Holes + G3/G4 Grade High-Efficiency Dust Filters |
Forced convection for efficient heat dissipation while 100% preventing dust and debris intrusion |
|
Anti-displacement stability |
Integrated Heavy-Duty Anti-Slip Base + High-Strength Anchor Bolt Connection |
Strong resistance to equipment vibration and impact, ensuring operational safety and accuracy |
|
Corrosion resistance |
Aluminum Alloy Anodizing / Stainless Steel Passivation Treatment + High-Quality Powder Coating |
Provides long-term protection in humid, acidic, alkaline, and salt spray environments |
|
Compatibility |
Compatible with 10-30kg Medium to Large Robotic Arms; Suitable for Harsh Applications in Automotive, Food, Pharmaceutical, and Chemical Industries |
Provides a top-level protective barrier for critical processes |
|
Customization |
Custom Colors Available (RAL/Pantone) |
Matches the workshop environment, enhancing a professional image |
(1) Fiber laser cutting machine (German import 2000W)
Cutting stroke: 1250mm × 3000mm
Maximum cutting thickness: 10mm
Features: High speed, high precision, less slag, smooth cutting surface
Can be used for recutting operations
Open structure, strong operability, good visibility
(2) CNC bending machine
Japanese digital controller + Mitsubishi servo amplifier
Bending length: 2000mm
Bending thickness: 8.0mm
Bending tolerance up to ±0.1mm
Quick machine setup, stable precision
(3) Hydraulic press
Customized enlarged table, suitable for large-size structural parts
Uniform and controllable pressing speed
Suitable for processing deep-drawn parts such as LCD display front frames and back shells
(4) Drilling/tapping/riveting/press riveting equipment
Ensuring that structural components have good connection and assembly properties.
1. What materials do you support?
We support a full range of metal materials, including aluminum, steel, and stainless steel, with sheet thicknesses ranging from 0.15mm to 10mm.
2. Can the housing color and surface treatment be customized?
Yes. Optional processes include:
Electrostatic powder coating (matte/gloss)
Anodizing
Brushed finish
Baking paint
Electrophoresis.
Colors can be customized according to your company's VI standards.
3. Are you a manufacturing plant in China?
Yes, we are a China Manufacturer located in Dongguan, with independent processing capabilities. We support custom orders based on provided drawings and OEM/ODM orders.
Contact Xinyang Industrial's sales and engineering team now! Please provide your robotic arm model, load, application environment, and specific protection requirements. We will quickly provide you with:
Professional technical assessment and optimization suggestions
Precise drawing design and confirmation
Competitive quotation
Efficient production and delivery scheduling
Choose Xinyang, choose a reliable partner in sheet metal protection!
